| Brand Name: | TICO |
| Model Number: | STC-ASM-T10 |
| MOQ: | 1 set |
| Price: | Negotiable |
| Delivery Time: | 20~25 working days |
| Payment Terms: | T/T |
Swagelok High Purity Titanium Three Electrode Test Cell for Lithium-lon Battery Research
Brief Introduction
The Swagelok battery features an extremely small electrode gap (less than 0.1mm), which allows it to perfectly simulate the testing environment of coin cells and pouch cells. This type of battery is smaller in volume and compatible with a broader range of electrolyte PH. It can operate in any working conditions except for temperature above 320℃, including strong acid and strong alkali systems, as well as both medium to high temperatures and low temperatures. The product is much smaller than traditional electrodes, making it convenient and practical for users.
Features
● The electrode gap is 0.1mm, which can perfectly simulate the testing environment in coin cell and pouch cell.
● Electrode posts of different diameter can be customized. (φ10mm, φ12mm, φ14mm, φ16mm, 20mm, other size is available)
● Each component of the product is adopted with high-precision processing technology to ensure high dimensional accuracy.
● This product has high corrosion resistance and is suitable for various severe environmental applications.
●The sealing performance is excellent, capable of withstanding packing deformation or "cold flow", improving thermal cycling performance and increasing the leak prevention capability.
●Excellent chemical stability at high temperatures and still keeping long service life even in fluid systems involving high temperature and corrosive media.
● Customized windows are available for the operator to use a microscope to view the internal reactions of the product.
Technical Parameters
|
Model |
STC-ASM-T10 |
|
Electrode post inner diameter |
φ10mm, φ12mm, φ14mm, φ16mm, 20mm, other size can be customized |
|
Connecting tube material |
PTFE |
|
Product material |
High purity molybdenum, pure titanium, titanium alloy |
|
Max working pressure |
10MPa |
|
Max working temperature |
200℃ |
Warranty
1 year's warranty with lifetime technical support.
FAQ
1. Are you a manufacture ?
A: Yes,our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.
2. Do you accept customized product ?
A: Yes. Most of our products can be customized to meet different requirments.
3. Will you provide test video before dispatch ?
A: Yes, we take test video for every equipment before dispatchm which will display how to use it.
4. Can you offer overseas installation service ?
A: Yes, we can dispatch professional engineer for on-site installion service.
|
|
