| Brand Name: | TICO |
| Model Number: | STC-DYG-300S |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 12~17 working days |
| Payment Terms: | T/T |
330mm Roller Battery Calendering Machine Hot Hydraulic Calender
Hot Hydraulic Calender with Winder &Unwinder for Lithium Battery Cathode &Anode Material
Brief Introduction for Hot Hydraulic Calender
STC-DYG-300S is a hot hydraulic rolling press machine, which is used for battery electrode rolling press process. Winding&unwinding device is optional.
Technical Parameters for Hot Hydraulic Roll Press Machine
| Model |
STC-DYG-300S |
|
Power |
AC220V |
| Heating temperature | RT~130℃ adjustable |
|
Pressing speed |
Max 6m/min |
|
Roller diameter |
φ330mm |
|
Roller material |
9Cr3Mo |
|
Roller surface hardness |
＞HRC65 |
|
Roller width |
330mm |
|
Pressing thickness |
Max 2mm |
|
Pressing accuracy |
±1.5μm |
|
Power |
3KW |
|
Installation size |
L2500 x W1500 x H1300mm ( Roll press machine + winding & unwinding device ) |
|
Compressed air |
0.5~0.8Mpa |
|
Weight |
≈ 600kg |
Features
• The pressing thickness is adjustable.
• It is designed with tension control.
• Winding&unwinding device with correction function.
• Touch screen control, high automation.
• RT~130℃ heating temperature adjustable.
Warranty
1 year's warranty with lifetime support.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China . We have more than 10 years experience for manufacturing battery lab research equipment .
We owns a professional R&D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
|
|
