| Brand Name: | TICO |
| Model Number: | STC-CFT-R300 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 5~8 working days |
| Payment Terms: | T/T |
Roll to Roll Continuous Electrode Slitting Machine
Product Details
It is used for roll-type material multiple strips continuous slitting. High accuracy slitting blade, which can carry out extremely high precision foil cutting. It is also widely applied in li-ion battery, metal foils, optical film and other functional film industries.
Key Features
• Ultra-fine tungsten alloy slitting blade, great performance in slitting electrode, longer lifetime.
• High accuracy of slitting width, no burrs, wave and indentation.
• The engagement is adjustable, the ratio of blade speed to material linear speed is adjustabel.
• It is capable to carry out slitting for various of material & thickness by adjusting the angle of charging &discharging.
• The winding tension is automatically controlled, the upper and lower shaft are independently adjustable within 50N.
• PLC control & HMI operation, easy for using.
Technical Parameters
| Model | STC-CFT-R300 |
| Voltage | AC220V±10%, 50/60Hz |
| Power | 1kw |
| Cutting trhickness | 100~300μm |
| Slitting width |
Range: 20~230mm, 20~280mm can be customized |
| Slitting blade diameter | φ100mm |
| Slitting accuracy | ±0.09mm |
| Burrs | ≤25μm |
| Slitting speed | Max. 4m/min |
| Dimension | L880 * W880 * WH700mm |
| Weight | 580kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
|
|
