| Brand Name: | TICO |
| Model Number: | STC-TMZ-300F2 |
| MOQ: | 1 set |
| Price: | Negotiable |
| Delivery Time: | 15~20 working days |
| Payment Terms: | T/T, |
Lab Transfer Lithium-ion Battery Electrode Coater
Brief Introduction
STC-TMZ-300F2 is a three-roller transfer coating equipment, which can be used for continuous coating and intermittent coating. It is convenient to apply for coating on various substrates, especially used for lithium-ion battery industry. This equipment is convenient for users to use, can meet the high requirements of coating accuracy and consistency, and with excellent drying effect.
Key Features
● Continuous and intermittent coating can be freely switched.
● Substrate tension control, stabilized belt moving, equipped with correction device.
● Lower & upper heating oven with good heating effect.
● 3-roller transfer coating with larger coating width.
● Comma coating blade metering, with precision adjustment mechanism to obtain high coating accuracy.
● PLC controller, touch screen operation, easy to operate.
● Solvent recovery processing device is optional.
Technical Parameter
| Model | STC-TMZ-300F2 |
| Voltage | AC380V, 3 phase 5 wire |
| Power | 20KW |
| Coating method | 3 rollers transfer coating |
| Coating mode | Continuous & intermittent coating |
| Roller width | 330mm |
| Effective coating width | Within 300mm |
| Running substrate thickness |
Aluminium foil: 8~30μm Copper foil: 8~30μm |
| Coating speed | 1~1.5m/min |
| Coating accuracy | ±3μm, except 10mm from the edge of the abnormal area |
| Single surface coating thickness range after drying | 20-200μm |
| Oven temperature | Max150℃, temperaure difference in single-section oven ≤±2.5℃ |
| Oven length | 1.5m/pcs, total 2pcs oven |
| Coating size accuracy | L≤±1mm, W≤±0.5mm |
| Compressed air | Exhaust pressure is about 0.5Mpa after drying, filtering and regulation |
|
Dimension |
L5000 * W1300 * H1800mm |
| Weight | 2200kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not included.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
|
|
