| Brand Name: | TICO |
| Model Number: | STC-EXJ-60L |
| MOQ: | 1 Piece |
| Price: | Negotiable |
| Delivery Time: | 5~8 working days |
| Payment Terms: | T/T, |
60L Planetary Vacuum Mixer for Battery Slurry Mixing
Brief Introduction
STC-EXJ-60L is suitable for mixing and dispersing the powder and liquid of various common types of batteries, and finally obtains evenly mixed battery slurry, and is also very suitable for high-viscosity technical processes. Viscosity range adapted to operating conditions ≤ 1200000 cP.
Key Features
● Vacuum environment, effectively eliminating air bubbles generated by the mixing process, good vacuum holding effect.
● Jacketed mixing bucket design, can be filled with cooling water, suitable for various process requirements.
● Form of jacket for temperature adjustment, the single-layer jacket for bucket wall is used for cooling or heating; and the single-layer jacket for bucket bottom is used for cooling or heating.
● Over temperature alarm system, safer and smarter.
● Operation failure stop: the frequency converter is self-provided with overload, overcurrent, overvoltage, leakage of electricity, short-phase protection.
● Variable cross-section Non-prismatic mixing design can make slurry get better mixing effect.
● Touch screen, simple operation, high automation.
Technical Parameters
| Model | STC-EXJ-60L |
| Power supply | AC 3×380V±5﹪, 50Hz |
| Lower bucket component | |
| Design volume | 88L |
| Effective volume | 29-60L |
| Bucket material | 304 stainless steel |
| Design ambient temperature | -10～+120°C |
| Mode of Movement | Mobile on casters |
| Mixing component | |
| Mixing power | 7.5KW |
| Speed of mixing propeller | 6-60rpm |
| Diameter of mixing propeller | 286mm |
| Pattern of mixing propeller | Non-prismatic twist type, 90° spiral line |
| Quantity of mixing propeller | 2 pieces |
| Distance between propellers | 4.6±2.5mm |
| Dispersed component | |
| Dispersion power | 11KW |
| Speed of dispersion | 315-3530rpm |
| Pattern of dispersion disc | Sawtooth pattern |
| Quantity of dispersion disc | 4 pieces |
| Material of dispersion disc | 304 stainless steel |
| Wiped-wall component | |
| Material of wiped-wall bracket | 304 stainless steel |
| Material of wiped-wall plate | PTFE |
| Base and lifting component | |
| Material | Carbon steel for high rigid structure |
| Lifting mode | Electric lifting |
| Lifting stroke | ≤570mm |
| Upper bucket component | |
| Material of upper bucket | 304 stainless steel |
| Feeding port of powder |
Quick-open interface DN100 with 90 sight glass one
|
| Feeding port of liquid | One ISO standard “1” quick-open joint |
| Spot-lighting | DN75 tempered glass sight glass one |
| Digital Vacuum Gauge Port | One M14×1.5 inner metric thread interface |
| Vacuum design demand |
Equipped with vacuum system, pumping capacity
8L/S (VSV-28).
|
| Vacuum holding |
-0.098MPa, it is higher than -0.085MPa after 24
hours holding, without leakage to bucket.
|
| Ground bearing | 1500Kg/㎡ |
| Dimension | L2050 * W1120 * H2090mm |
| Weight | About 1450kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch ?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
|
|
