| Brand Name: | TICO |
| Model Number: | STC-TMZ-400F3 |
| MOQ: | 1 set |
| Price: | Negotiable |
| Delivery Time: | 15~20 working days |
| Payment Terms: | T/T, |
Roll to Roll Coating Machine with Three-Section Drying Oven for Battery Electrode Production
Brief Introduction
STC-TMZ-400F3 is a three-roller transfer coating equipment, which can be used for continuous coating and intermittent coating. It is convenient to apply for coating on various substrates, especially used for lithium-ion battery industry. This equipment is convenient for users to use, can meet the requirements of coating accuracy and consistency, and with excellent drying effect. It is the ideal choice for lithium-ion batteries, super capacitors, nickel batteries, etc.
Key Features
● The gluing roller is controlled by double servo rods, which can be adjusted to wind up according to different viscosity slurries.
● Continuous and intermittent coating can be freely switched.
● Substrate tension control, stabilized belt moving, equipped with correction device.
● Lower & upper heating oven with good drying effect.
● 3-roller transfer coating with larger coating width.
●Comma coating blade metering, with precision adjustment mechanism to obtain high coating accuracy.
● Adopting analog signal to control power heating, the heating system has high precision and long lifetime:
● PLC controller, touch screen operation, easy to operate.
● Solvent recovery processing device is optional.
Technical Parameter
| Model | STC-TMZ-400F3 |
| Voltage | AC380V |
| Power | 30KW |
| Coating method | 3 rollers transfer coating |
| Coating mode | Continuous & intermittent coating |
| Roller width | 400mm |
| Effective coating width | Within 350mm |
| Running substrate thickness |
Aluminium foil: 8~30μm Copper foil: 8~30μm |
| Coating speed | About 1.5~3m/min |
| Coating accuracy | ±3μm |
| Single surface coating thickness range after drying | 20-200μm |
| Oven temperature | Max150℃, temperaure difference in single-section oven ≤±2.5℃ |
| Oven length | 1.5m/pcs, total 3pcs oven |
| Coating size accuracy | L≤±1mm, W≤±0.5mm |
| Compressed air | Exhaust pressure is about 0.5Mpa after drying, filtering and regulation |
|
Dimension |
L6500 * W1300 * H1800mm |
Warranty
1 year warranty with lifetime support. Man-made damage is not included.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
|
|
